Mighty Mule 350 - Wiring Accessories

29
rev 07.12.12
1
23
4
5
7
6
Photo Beams
(R4222)
Push Button Control
Automatic Gate Lock
(FM143)
Vehicle Sensor (FM138)
Edge Sensor
NOTE:
Connections are for typical applications.
For additional connection options not illustrated here
refer to the accessory manual for details.
2
1
1
4
1
1
Keypad
(FM137)
5
1
2
1
2
ABC
3
DEF
4
GHI
5
JKL
6
MNO
7
PRS
8
TUV
9
WXY
0
3
RED BLACK
CHARGING
POWER
RCVR
GRN
BLK
RED
EXIT
SAFETY
EDGE
CYCLE
COMMON
LINK
AUX
OUT
SOLAR
INPUT
18VAC/
H L
(+12 v)
(See additional wiring digram on pg. 30)
(+12 v)
( – )
( – )
WIRING ACCESSORIES
DIP switch 4 set to
OFF position (Default)
