Migomag SIM 200 LCD - Drive Bracket Assembly Part List

Operators Manual
37
Drive Bracket Assembly Part List
NO Part Number Descripon QTY
1
87003001
Drive Motor 1
2
87003005 Holding screw
2
3
87003006 Wire inlet guide tube
1
4
87003002 Wire feed bracket
1
5
87003007 Sha for drive gears
2
6
87003008 Sha sleeve for drive gears
2
7
87003009 Drive gear
2
8
87003010 Drive gear pin
4
9
87003011 Motor drive gear
1
10
87003012 Sleeve for drive roller
2
11
87003013 Washer for drive gear
1
12
87003014 Drive roller
2
13
87003003 Washer for driving roller
2
14
87003004 Securing screw for drive roller
2
15
87003015 Pressure roller pin
2
16
87003016 Idler arm pin
2
17
87003017 Washer for pressure rollers
4
18A
87003018 Le Idler are Bracket
1
18B
87003019 Right Idler are bracket
1
19
87003020 Tension spring
1
20
87003021 Euro adaptor suit SIM
1
21
87003022 Tension adjusng screw
2
22
87003023 Tension adjusng handle
2
23
87003024 Spring for tension
2
24
87003025 Tension adjusng handle cover
2
25
87003026 Center guide tube
1
26
87003027 Central adaptor guide tube
1
