Milesight Technology MS-C5374-PB - Page 63

57
Table 4-5-3 Description of the buttons
Parameters
Function Introduction
Record Video Sections
Six different periods are available(5, 10, 15, 20, 25, 30 sec).
Pre-record
Reserve the record time before alarm, 0~10 sec.
Snapshot
The number of snapshot, from 1 to 5.
Snapshot Interval
It cannot be edited unless you choose more than 1 to Snapshot.
External Output Action
Time
Length of time an alarm lasts, this cannot be edited unless when you enable
the External Output on the Alarm Action firstly.
Audio Action Settings
Set the audio schedule to trigger different audio files and action times in
different time, which is corresponded to alarm action.
Play Audio Interval
Auto/ 10 seconds/ 30 seconds/ 1 minute/ 5 minutes/ 10 minutes are available.
Note:
You can customize the schedule of Audio Action.
Audio Alarm
Enable the Audio before using Audio Alarm function.
