2. Hardware Introduction
2.1 Overview
2.2 Dimensions (mm)
2.3 LED Indicators
LED
Indication
Status
Description
SYS
System Status
Green Light
Static: the system is running properly
Red Light
The system goes wrong
LoRa
LoRa Status
Off
Packet Forwarder mode is running off
Green Light
Packet Forwarder mode is running well
LTE
Cellular Status
Off
SIM card is registering or fails to register
(or there are no SIM cards inserted)
1 LoRa Antenna Connector
2 Vent Plug
3 SIM Slot
4 LED Area & Type-C Port & Reset Button
SYS: System Indicator
LoRa: LoRa Indicator
LTE: Cellular Indicator
5 DC Power Connector (Solar Connector)
6 Ethernet Port (PoE)
7 Mounting Bracket
