How to fix a Miller XMT 350 CC/CV with no weld output and is completely inoperative?
If your Miller Welding System has no weld output and is completely inoperative: * Place the line disconnect switch in the On position. * Check and replace the line fuses if necessary, or reset the circuit breaker. * Check for proper input power connections.
What to do if my Miller XMT 350 CC/CV has no weld output but the meter display is on?
If your Miller Welding System shows the meter display is on but there's no weld output, the input voltage may be outside the acceptable range. Check, repair, or replace the remote control. Alternatively, the unit may have overheated; allow it to cool with the fan on.
Why does my Miller XMT 350 CC/CV have erratic or improper weld output?
Erratic or improper weld output from your Miller Welding System can occur due to several reasons. Ensure you are using the correct size and type of weld cable. Also, clean and tighten all weld connections. Finally, verify that you have the correct polarity.
General| Rated Output | 350 A at 34 VDC, 60% duty cycle |
|---|---|
| Welding Amperage Range | 5 - 425 A |
| Output Current Range (CC) | 5 - 425 A |
| Input Power | 208 V, 3-Phase, 50/60 Hz |
| Welding Processes | Stick, TIG, MIG, Flux-Cored |
Explains hazard symbols used throughout the manual for identification.
Details various hazards associated with arc welding processes and general electrical safety.
Covers specific symbols for equipment setup, operation, and maintenance procedures.
Lists chemicals known to cause cancer or birth defects as per California law.
References key safety standards and regulations relevant to welding equipment.
Explains electromagnetic field effects and precautions for users, especially those with medical implants.
Explains the meaning of warning labels and symbols found on the equipment.
Details disposal instructions for waste electrical and electronic equipment in the EU.
Provides a glossary of common symbols and their definitions used in welding.
Details EMF and EMC compliance requirements for products sold in the European Union.
Indicates where to find the product's serial number and rating information.
Lists technical specifications including input power, output ratings, and IP rating.
Illustrates the output capabilities (voltage vs. amperage) in CC and CV modes.
Explains how duty cycle affects operation and how to prevent overheating.
Guidelines for choosing a safe and suitable installation site for the welding unit.
Step-by-step instructions for safely connecting the unit to a 3-phase power supply.
Provides recommendations for circuit sizing, fuse rating, and conductor selection.
Details how to connect output cables and choose appropriate sizes based on length.
Describes the function, pinout, and usage of the remote control receptacle.
Explains the 115V AC receptacle and its associated circuit protection.
Covers the setup and operation procedures for shielding gas connections.
Identifies and explains the function of each control on the front panel.
Describes the readings displayed on the unit's meters during idle and welding.
Details how mode switch settings affect process selection and output control.
Procedure for initiating and performing TIG welding using the Lift-Arc start method.
Instructions for starting an arc using the Stick welding mode.
Outlines recommended maintenance tasks and schedules for the equipment.
Instructions for cleaning internal components using compressed air for dust removal.
Explains error codes and diagnostic messages shown on the unit's meters.
Provides solutions for common operational problems and potential issues.
