Chapter 2 - Specification
Basic Machine Specifications
Machine Model SL6 SL10
CAPACITY
Swing Over Way Cover 20" 510 mm
Swing Over Carriage 9" 230 mm
Bar Capacity, Diameter 1.65" 42 mm 2.55" 65 mm
Chuck Size 6" 152 mm 10" 250 mm
Machine Weight 7000 lb 3180 kg
Spindle Load Capacity (Work Holding + Part) 300 lb 135 kg 450 lb 200 kg
Turning Diameter, Max with 8 & 12 Station Turret 12.25" 310 mm
Spindle Nose Type A2 - 5 A2 - 6
TOOLING – CONTACT FACTORY FOR LIVE TOOLING SPECIFICATIONS
Turret 1" 25mm, 8 Position
Optional Turret ¾" 20mm 12 Position
Tool Shank Size – Standard 8 Station Turret 1 x 5" 25 x 125mm
Tool Shank Size – Optional 12 Station Turret ¾ x 5" 20 x 125mm
Boring Bar Capacity – Standard 8 Station Turret 1.5" 38mm
Boring Bar Capacity – Option 12 Station Turret 1.25" 32mm
Current/Voltage requirements
SL6 SL10
Voltage 208-240 VAC 208-240 VAC
Current 60 Amps 80 Amps
Transformer 23 KVA 30 KVA
Coolant Capacities
SL6 SL10
Gallons 36 36
Liters 140 140
Coolant Recommendation
Consult with a reputable coolant supplier in your area. You should use non-toxic, non-
corrosive, and non-flammable coolant. Avoid chlorine and sulfur, which may harm the
paint finish.
Hydraulic Fluid Tank Capacity
SL6 SL10
Gallons 10.5 10.5
Liters 40 40
Use Mobil DTE24 or Equivalent
