PL-590 XRS-5 Transducer Page 5
Specifications
Specifications
Process Application:
{
liquids and slurries
{
Measurement Range
{
0.3 to 8m (1 - 26 ft) typical (application variables apply)
{
Vessel Pressure
{
vented to atmosphere
Operation:
{
Beam Angle
{
10°
{
Frequency
{
43 KHz
{
Temperature Sensor
{
internal
{
Supply Source
{
transducer shall only be supplied by Milltronics certified
controller
Environmental:
{
Location
{
indoor / outdoor
{
Ambient temperatures
{
-20 to 65 °C (-4 to 149 °F)
{
Altitude
{
2000 m maximum
{
Pollution degree
{
4
Construction:
{
Housing
{
Kynar Flex
®1
body and Hypalon
2
face
{
XRS-5C has SS conduit connection
{
Mounting
{
XRS-5: 1” NPT or BSP conduit connection
{
XRS-5C: 1” NPT
Cable:
{
2 wire shielded / twisted, 0.5 mm
2
(18 AWG) PVC jacket
Ingress protection:
{
IP-68
Weight
3
:
{
1.2 Kg (2.6 lb)
Options:
{
factory flanged to suit ANSI , DIN or JIS standard
{
split flange (field mount) to suit ANSI, DIN or JIS standard
{
submergence shield (flooding applications)
Cabling (maximum run):
{
365 m (1200 ft) using RG-62 A/U coaxial cable
{
365 m (1200 ft) using 2-wire twisted pair / braided and foil shielded 20 AWG (0.5
mm
2
), PVC jacket (EnviroRanger ERS 500 only)
Approvals:
{
XRS-5: CE
4
, CSA, FM, CENELEC/ATEX, SAA, see device nameplate
O
XRS-5C: CSA
O
Please verify against the device nameplate
1
Kynar Flex
®
is registered trademark of ELF Atochem.
2
Hypalon
®
is a registered trademark of Du Pont
3
approximate weight of transducer with standard cable length
4
EMC performance available upon request
