Milltronics XRS-5 - Installation

PL-590 XRS-5 Transducer Page 9
Installation
Installation
Outline and Dimensions
Standard Flange (optional)
Submergence Shield Split Flange (optional)
Refer to Milltronics
instruction manual PL-530.
127mm
(5.0”)
89mm
(3.5”)
127mm
(5.0”)
ANSI, DIN or JIS
standards
155mm
(6.1”)
124mm
(4.9”)
ANSI, DIN or JIS
standards
133mm
(5.2”)
nominal
