PL-590 XRS-5 Transducer Page 13
Applications
Applications
Notes:
• The transducer is to be used only in the manner outlined in this
instruction manual.
• This transducer requires no maintenance, and is recommended for use
with liquids only.
• The OCM III requires the use of the TS-2 external temperature sensor.
The internal temperature sensor in the XRS-5 cannot be used.
Open Channel Meter
Refer to OCM manufacturer specification for proper point of head
measurement.
The OCM III requires the use of the TS-2 external temperature sensor
instead of the XRS-5 internal temperature sensor. The use of an external
temperature sensor provides better temperature tracking in applications
where the temperature can change quickly.
typical flume or weir
refer to Milltronics
transceiver manual for
minimum distance above
maximum head.
