25
c) Measure J6-1. Manually move ECC moto r
shaft to adjust f eedback pot for +1 VDC ±
0.1 VDC (car efully use lar ge screwdriver
through center hole in circuit board to man-
ually turn motor shaft).
d) Measure J6-2. Adjust zero pot (VR2) for
-1 VDC ± 0.05 VDC.
e) Measure J6- 4. Adjust control-offset po t
(VR7) for -1 VDC ± 0.05 VDC.
f) Measure J6- 3. Sho uld r ead 0.00 VDC o r
close to it.
g) Measure J6-6 . Adjust feedback o ffset
(VR9) for 0.00 VDC ±0.1 VDC.
h) Measure J6- 7 with DVM set to mA r ange
(VDC r ange for 1 -5 VDC output). Adju st
feedback zero (VR5) for 4 mA ±0.1mA (1
VDC ±0.1 VDC).
i) If any Initial adjustment s for zero (VR 2),
control o ffset (VR7) , fe edback of fset
(VR9), or feedback zero (VR5) can no t be
attained set VR3 fu ll CCW an d VR4 full
CW and co mplete paragraph 4.8.1.3 ste p
2. a through 3. h.
4. Adjustments for span (V R1) a nd feedback
span (VR6).
a) Disconnect motor lead, J1. Apply 20 mA (5
VDC) input signal. Reset DVM for VD C
range.
b) Measure J6-1. Manually move ECC moto r
shaft to adjust feedback pot for +5 VDC.
c) Adjust span p ot (VR 1) u ntil bo th mo tion
LEDs (CR5 and CR6) are off.
d) Measure J6 -6. Ad just feedback s pan
(VR6) for - 4 VDC.
5. Reconnect P1 and apply power. Vary input sig-
nal from low to high and observe correct oper-
ation.
6. Apply a 4 mA (1 VDC) control signal and allow
motor to run until it stops. Disconnect power.
7. Manually turn pump
stroke adjust to a position
of 0% for direct-acting or 100% for reverse-act-
ing.
8. Install ECC to pump. Do not rotate ECC shaft.
If necessary, slightly r otate pump cou pling for
proper engagement with ECC drive pin. Install
and tighten mounting bolts.
9. Using a s crewdriver, rotate motor s haft to turn
pump stroke adjust to minus 1% (this is 1 per-
cent below 0% reading, shows as “9 ” on most
pump micrometer rin gs). (Max Roy pump has
mechanical stops).
10. Low signa l a djust: Disconnect motor lea d,
J1. Ap ply a 4 m A (1 VDC) signal a nd ad just
zero pot (VR2) until both motion lights are off
(CR5 and CR6). Adjust lower limit LED (CR3)
until just on (VR3), if needed. Adjust feedback
zero pot (VR5) to 4 mA (1 VDC), if needed.
NOTE
The MaxRoy B, Milr oyal B, C, G, MacRoy
G, and D use s a 20 :1 gearbox. It req uires
200 tu rns at the actuator ha ndwheel to
adjust the pu mp str oke 10 tu rns (0 % to
100%). The Milroyal D uses a 5:1 or 12 :1.
11. Manually turn pump stroke adjust to a position
of 100% (101%) for direct-acting or 0% ( -1%)
for r everse-acting. (Max Roy pump h as
mechanical stops.)
12. High signal adjust: Apply 20 mA (5 VDC) sig-
nal an d ad just span p ot ( VR1) until bo th
motion light s are of f. Adjust upper limit LED
(CR4) until jus t on (VR4), if needed. Adjust
feedback s pan pot ( VR6) to 20.00 mA ( 5
VDC), if needed.
13. Verify:
Verify tra vel with lo w a nd h igh sign al.
Readjust fe edback zero a nd fee dback sp an if
needed for travel. Readjust limit s until limit
LEDs are just on, if needed.
14. Disconnect input and output control signal wir-
ing, reconnect all co nnectors, and install ECC
cover.
