Milton Roy MAXROY B - Electronic Capacity Control Parts List

31
6.3 ELECTRONIC CAPACITY CONTROL PARTS LIST
Model: Code:
MacRoy G & D A
mRoy B
maxRoy B C
Model:
Code:
Milroyal B D
Milroyal C E
Milroyal D F
Milroyal G G
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QUANTITY REFERENCE
CODE
15 10 Base (Explosion Proof) 2810249062 1
20 Bushing, Bronze 2370112052 1 A, B, C, D, F, G
20 Bushing 2370079152 1 E
30 Seal 4080091020 1 A, B, C, D, F, G
40 Motor (115 VAC, 224M) 2280032000 1 A, C, D, F, G
40 Motor (115 VAC, 224N) 2280035000 1 B
40 Motor (115 VAC, P-400) 2280039000 1 E
40 Motor (220 VAC, 227D) 2280036000 1 A, C, D, F, G
40 Motor (220 VAC, 227E) 2280034000 1 B
40 Motor (220 VAC, P-400) 2280039010 1 E
- Jumper, Reverse Acting 40229 1
- Wire, BLU, 22 gauge, P-400
only
4060387150 4 inch
50 Screw, No. 10-32 x 1/2 4050005063 4
55 Ground Screw, Green,
Explosion Proof Only
4050306021 2
56 Ground Lug, Exp Proof Only 4913003001 2 A, B, C, D, F, G
60 Adapter Plate 152067062 1
61 Shrink Tubing, 1/8 4911478040 2 inch
62 Resistor, 200 ohms, 115VAC 4910732003 1 A, B, C, D, F, G
62 Resistor, 750 ohms, 220VAC 4910732014 1 A, B, C, D, F, G
-63 Wire, BLU, 22 gauge 4060387150 7.5 inch
-64 Wire, YEL, 22 gauge 4060387140 9 inch
65 Cap., 4 UF, 115 VAC, 50/60
Hz
4913002000 1 A, B, C, D, F, G
65 Cap., 4 UF, 220 VAC, 50 Hz 4913002000 1 E
65 Cap., 1.5 UF, 220 VAC, 50/
60 Hz
4913002001 1 A, B, C, D, F, G
65 Cap, 15UF, 115VAC, 50/60
Hz
4910774008 1 E
- Items not shown.
