QUICK START GUIDE
NOTE: Read and understand safety instructions before proceeding
READ
- Read and comply with all safety instructions pr esented in this m anual. In order to comply with th e
requirements of agency approvals (see data plate), specifications for conduit connections, wire gauge
and type, fastener torque ratings, and operating conditions must be adhered to.
CONNECT
- Connect AC power. Use conduit connections or cable glands.
- Ground unit.
- Connect command signal.
- Connect feedback signal.
VERIFY
- Voltage selector switch is set to the required voltage (115 or 230 VAC).
- DIP switches are set for desired operation.
- Command input signal is set to desired operation 4-20 mA or (1-5 VDC). Factory set at 4-20 mA.
- Feedback signal output is set to desired operation 4-20 mA or (1-5 VDC). Factory set at 4-20 mA.
- Loss of command signal action (unit moves to low signal position or (hold last position). Factory set-
ting moves unit to low signal position.
- If reverse action is required (optional, call factory).
HAZARDOUS VOLT AGES ARE PRES ENT ON THE CIRCUIT BOARD . TO
PREVENT IGNITION OF HAZARDOUS ATMOSPHERES, COVER MUST BE TIGHT
WHILE CIRCUITS ARE ENERGIZED.
APPLY POWER
- Apply command signal.
- Apply AC power.
