33
150 Connector (P1), AMP, 9 Pin 4910363008 1
160 Ties, Cable 4060270010
170 Identification Plate, Terminal 152097099 1
180 Square Ring Seal 4080133440 1
190 Gear, Worm, Single Lead 151984001 1 A, B, C, D, E, G
190 Gear, Worm, Double Lead 151984002 1 F
200 Pin, Spring, 3/32 x 1/2 4010002052
220 Circuit Board (115 VAC, 230
VAC, 50/60 Hz), Specify
Pump
30300 1 A, B, C, D, F, G
220 Circuit Board (115 VAC, 230
VAC, 50/60 Hz), Specify
Pump
39320 E
280 Cover, Short 2810248362 1 A, B, C, D, F, G
280 Cover, Tall 2810248462 1 E
290 Bushing, Bronze 152199052 1
300 Shaft, Hand Wheel 152082414 1 A, B, C, D, F, G
300 Shaft, Hand Wheel 2680059014 1 E
310 O-ring, 0.239 x 0.070, BUNA 4080109071 1
320 Spring 4030125042 1
340 Clip, Retaining 4040107135 1
350 Knob, Hand 2550039000 1
360 Pin, Spring, 0.125 x 1-1/4 4010003132 1
370 Label, Explosion 2530214000 1
370 Label, NEMA 4 2530209062 1
-380 Shaft, Drive Coupling 2520148006 1 E
-385 Pin, Spring, 1/8 x 5/8 4910764006 1 A, C, D, E, F, G
390 Rivet 4050087021 2
400 Plug 4020009137 2
410 Gearbox(20:1) Double Stage
21523 1 A, C, D, G
410 Gearbox, Single (5:1) CALL FACTORY 1
F(Low Pressure)
41
0 Gearbox(12:1) Double Stage CALL FACTORY 1 F(
High
Pressure)
510
Conn
ector (P4), 2 Position
Phoenix
4911499060 1
520 Connector (P5), 4 Position
Phoenix
4911499050 1
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QUANTITY REFERENCE
CODE
- Items not shown.
