6.7 PARTS LIST FOR MAXROY ECC MOUNTING ADAPTER
Model: maxRoy “B”
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QUANTITY REFERENCE
CODE
19 - Kit, ECC Retrofit Mount,
Includes The Following Parts:
Items 200 Through 890
PARTSKIT303 1
200 Stroke Adjustment Sleeve 60680179006 1
800 Set Screw M-12 x 40 64350068535 1
805 Hex Nut M-12 64350000085 1
810 Shoe 60190269062 1
820 Basic Stroke Adjustment
Assembly, (Sold as a Kit)
Includes the following:
63050654010 1
Pin, Spring 0.156 x 7/16 4010004012 1
O-ring, 2-223, Buna N 4080095141 1
Knob, Stroke Indicator 60550026077 1
Drum, Control 60550047074 1
Ring, MAXROY B 64400002021 2
Lubricant, O-ring 4070311000 1
830 Lockwasher, Metric for #6
Screw
4040150091 3
835 Screw, Socket HD Metric #6 4052003021 3
840 Mounting Bracket 2040151006 1
845 Pin, ECC, MAXROY B 2110057052 1
850 Link, MAXROY B 2140029006 1
855 Dowel Pin 3/16 x 1” Lg. 4010022051 1
860 Coupling 2520128000 1
865 Coupling Nut 2090034006 1
870 Lockwasher 3/8 Med. 4040041022 4
875 Screw, Hex Hd 3/8 Med. 4050018096 4
880 ECC See Table 3 1
890 Label, Warning 2530097000 1
- Items not shown.
