49
6.9 PARTS LIST FOR MILROYAL ECC MOUNTING ADAPTER AND GEAR DRIVE
Model: Milroyal “C”
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QUANTITY REFERENCE
CODE
21 - Kit, ECC Retrofit Mount,
(Manual Adjust to ECC
Mount) Includes Items 101
thru 631, Before 1990
30270
- Kit, ECC Retrofit Mount,
(Manual Adjust to ECC
Mount) Includes Items 101
thru 631, 675, 693, & 694,
After 1990
39647
101 Set Screw 5/8-11” x 1 Lg. 4050047054 1
102 Lead Screw 2560059006 1
103 Seal 4080123211 1
105 Dowel Pin 4010023072 1
601 Stud 3/8-16” x 2 Lg. 2430061014 3
611 Adapter 2720116062 1
615 Flatwasher 3/8” 4040009012 3
621 Lockwasher 3/8” 4040041022 3
625 Hex Nut 3/8” 4050066012 3
631 Spline Shaft 2520147006 1
- Gear Parts, Includes The Fol-
lowing Parts: Items 635
Through 696
1
635 Lockwasher 5/16” 4040040028 4
641 Hex Hd. Cap Screw 5/16-18”
x 1 Lg.
4050017116 4
651 ECC, Includes ECC and
Gearbox without Lead Screw
See Table 5
655 Adapter Plate 2720115062 1
661 Soc. Hd. Cap Screw 3/8-16” x
5/8 Lg.
4050029086 4
665 Key 4040056031 1
671 Key 2110058006 1
675 Indicator, Tube 2450029062 1
675 Indicator, Tube Decal, Part of
P/N 39647
2530121062 1
680 Street Elbow 4020031011 1
685 Spline Bushing 2370091006 1
- Items not shown.
