3ENGLISH
MAINTENANCE
Wipe the aperture lens and the body of the laser with a clean soft cloth. Do not use solvents.
Although the laser is dust and dirt resistant to a certain degree, do not store in dusty places as
long term exposure may damage internal moving parts.
If the laser is exposed to water, dry the laser level before returning it to the carrying case to
prevent corrosion damage.
TECHNICAL DATA
Laser Class 2
Self-Leveling Range ± 4°
Self-Leveling Time  3 s
Battery technology Li-Ion
Voltage DC 12 V
Protection class (water and dust
protection)
IP54*
Max. altitude 2000 m
Relativ air humidity max. 80%
Pollution degree according to
IEC 61010-1
2**
Pulse duration t
P
 80 s
Functions 3 planes (1 horizontal, 2 vertical)
Frequency 10 kHz
Projections 3 x 360° lines green ( 1x horizontal, 2x vertical)
Diode Quantity 3
Diode type 50 mW
Operating time 15 hrs with M12 4.0 Ah Battery
Tripod mount 1/4" / 5/8" thread
Suitable detector Milwaukee LLD50
Laser Line
Width < 9.53mm @ 30m
Wavelength 510 - 530 nm Laser Class II
Max. Power  8 mW
Accuracy +/- 3 mm / 10 m
Fan angle 360°
Colour green
Working Range 38 m (with detector 50 m)
Recommended ambient operating
temperature
-10°C - +40 °C
Storage Temperature -20°C - +50 °C
Recommended battery types M12 B...
Dimensions 193 mm x 110 mm x 168 mm
Weight (incl. Battery 6 Ah) 1607 g
* The Lithium-ion battery and the battery compartment are excluded from IP 54.
** Only non-conductive deposits occur, wherby occasional temporary conductivity caused by
condensation is expected.
SPECIFIC CONDITIONS OF USE
The product is designed for mainly indoor use. For outdoor use make sure that the boundary
conditions are the same as for indoor use.
The laser is innovatively designed for a very broad range of professional jobs, including:
- Aligning tiles, marble, cabinets, borders, moldings and trimmings
- Marking layout for doors, windows, rails, stairs, fences, gates, decks and pergolas installation.
- Transferring reference point for light installations, vents, transfer of heights, levelling perimeter
walls, wall studs, setting out tracks on fl oors and all other professional use.
- It is intended for determining and checking horizontal and vertical lines.
Do not use this product in any other way as stated for normal use.
