Make the media without uncut area
By over wrapping the start point and the end point arbitrarily, you can
make the media without uncut area.
Specify the over cut function (valid/invalid) and the length of the over cut.
If the length of the over cut is set, when cut starts, cut will be performed
from the position to the front by the specified length and the tool will move
up going too far at the end.
1
Press the key in the local mode.
2
Press the jog key or to select [SET UP] .
3
Press the key.
4
Press the jog key or to select [OVER
CUT] .
5
Press the key.
6
Press the jog key or to select OVER
CUT setting.
• Set values : OFF or a value from 0.1 to 1.0mm (0.1mm unit)
7
Press the key.
8
Press the key twice for terminating this function.
• Setting proper over cut can reduce uncut area of start and end point of a media easy to bend. If too
large value is set, the result may have a rupture
Over cut
part
DATA CLEAR <ENT >
FUNCTION
SET UP <ENT>
ENTER/HOLD
OVER CUT < e n t >
OVER CUT : OF F
ENTER/HOLD
OVER CUT : 0 . 3mm
0.1 ~ 1mm
0.1 ~ 1mm
ENTER/HOLD
END
