- 4 -
High-speed mode
•A mixture of CMYK ink is laminated to the specified height for the braille.
•The settings can be altered to vary color image and braille printing order.
•Option settings are available to allow white ink to be printed to cover the braille.
Target Environment
symbol in the table below indicates the mode is compatible.
UJF-3042MKIIe
Ink sets and supported braille modes
Print conditions
In RasterLink, device profiles with the following conditions should be installed for each ink set.
UJF-6042MKIIe
Ink sets and supported braille modes
4 Color+SP
Ink set Special color set Standard mode High-speed mode
LH-100 CMYK WW
WCI
WP
CIP
LUS-120 CMYK WW
WCI
WP
CIP
LUS-150 CMYK - Not supported
LUS-200 CMYK - Not supported
• When a job is created, output settings are automatically applied to braille jobs.
Mode Standard mode High-speed mode
Media [Braille] Standard mode [Braille] High-speed mode
Resolution 1200 x 1200 VD 600 x 1200 VD
No. of passes 16 passes 16 passes
Ink set Special color set Standard mode High-speed mode
LH-100 CMYK CIPWW
LUS-120 CMYK CIPWW
LUS-150 CMYK - Not supported
LUS-200 CMYK - Not supported
Laminates using a mixture of CMYK ink
Options are available to allow printing of white ink
over the braille.
Braille printed over color image
Color image printed over braille
Media
Media
