Mimosa Backhaul Reset Process
Copyright © 2014 Mimosa Page 5
Local Device Reset
Product Applicability: B5-Lite
This process is to restore the device to the factory state when the device is physically available.
This process is to restore the device to the factory state when the device is physically available.
Follow these steps to reset the radio:
Disconnect the Ethernet cable from the radio.1.
Insert a paper clip into the hole next to the Ethernet port (see image below), and then plug the Ethernet cable2.
back in. The green LED will blink slowly after 2 seconds, and then fast after 4 seconds.
Let go of the reset button when the green LED starts blinking fast.3.
The radio will then reboot for approximately 90 seconds.4.
Connect your computer to the LAN input of the PoE.5.
With a web browser, navigate to 192.168.1.20.6.
Reset Button
