Mimosa Backhaul B5c User Manual

Mimosa Backhaul Help Content
Mimosa Backhaul SNMP Interface
Copyright © 2014 Mimosa Page 172
1.3.6.1.4.1.43356.2.1.2.2.1.0 mimosaLongitude.0 INTEGER: -
12194368
3
Wireless > Location > Location
Data > Latitude (Local)
1.3.6.1.4.1.43356.2.1.2.2.2.0 mimosaLatitude.0 INTEGER:
3728529
3
Wireless > Location > Location
Data > Longitude (Local)
1.3.6.1.4.1.43356.2.1.2.2.3.0 mimosaAltitude.0 INTEGER: 65
meters
Wireless > Location > Location
Data > Altitude (Local)
1.3.6.1.4.1.43356.2.1.2.2.4.0 mimosaSatelliteSNR.0 INTEGER: 380
dB
1
Wireless > Location > Satellite
Information > Satellite Avg SNR
1.3.6.1.4.1.43356.2.1.2.2.5.0 mimosaSatelliteStrength.0 INTEGER:
good(1)
Wireless > Location > Satellite
Information > Satellite Signal
Strength
1.3.6.1.4.1.43356.2.1.2.2.6.0 mimosaGPSSatellites.0 INTEGER: 11 Wireless > Location > Satellite
Information > Total Satellites >
GPS
1.3.6.1.4.1.43356.2.1.2.2.7.0 mimosaGlonassSatellites.0 INTEGER: 8 Wireless > Location > Satellite
Information > Total Satellites >
GLONASS
1.3.6.1.4.1.43356.2.1.2.2.8.0 mimosaClockAccuracy.0 INTEGER: 156
PPB
2
Wireless > Location > Satellite
Information > Clock Accuracy
TDMA Settings
OID Object Output Example UI Location
1.3.6.1.4.1.43356.2.1.2.4.1.0 mimosaWirelessMode.0 INTEGER: station(2) Wireless > Link > TDMA
Configuration > Wireless
Mode
1.3.6.1.4.1.43356.2.1.2.4.2.0 mimosaWirelessProtocol.0 INTEGER: tdma(1) Wireless > Link > TDMA
Configuration > Wireless
Protocol
1.3.6.1.4.1.43356.2.1.2.4.3.0 mimosaTDMAMode.0 INTEGER: A(1) Wireless > Link > TDMA
Configuration > Gender -
Traffic Split
1.3.6.1.4.1.43356.2.1.2.4.4.0 mimosaTDMAWindow.0 INTEGER: 4 ms Wireless > Link > TDMA
Configuration > TDMA
Window
1.3.6.1.4.1.43356.2.1.2.4.5.0 mimosaTrafficSplit.0 INTEGER:
symmetric(1)
Wireless > Link > TDMA
Configuration > Gender -
Traffic Split
