Mimosa Backhaul Performance
Copyright © 2014 Mimosa Page 23
favor of higher SNR. This is because SNR at the receiver limits the MCS more than the distortion from the Tx
amplifier.
The table below shows the maximum recommended Tx Power settings for a given SNR to achieve the highest MCS
index. Auto Everything dynamically adjusts Tx Power, or these steps should be followed in manual mode:
Note the lowest SNR on Dashboard > MIMO Status.1.
Find the SNR in the first column of the table below.2.
Set Tx Power to a value in the second or third column, depending on the number of channels used.3.
B5/B5c Power Table
SNR (dB)
Dual-Channel
Tx Power (dBm)
Single-Channel
Tx Power (dBm)
1-14 27 30
15-18 26 29
19-24 25 28
25-28 24 27
29-40 23 26
>40 63-SNR* 66-SNR*
* Subtract the SNR found in step 2 above.
