Mimosa C5c User Manual

Mimosa Client Help Content
Mimosa Clients Troubleshooting Guide
Copyright © 2014 Mimosa Page 87
Try changing to the same static values on both router and Mimosa radio (e.g. force 100BaseT or 1000BaseT13.
on both sides). The Ethernet port speed setting is located on the Management Miscellaneous Settings page.
If possible, try replacing the PoE Injector in order to determine if the port negotiation issue is with the Radio14.
or the PoE Injector.

Mimosa C5c Specifications

General

Antenna Connector	2x RP-SMA
Max Power Consumption	10W
Product Name	Mimosa C5c
Category	Wireless Access Point
Max Transmit Power	27 dBm
Frequency Band	5 GHz
Channel Bandwidth	20/40/80 MHz
Ingress Protection	IP55
Operating Temperature	-40 to +55° C (-40 to +131° F)
Wireless Protocol	802.11ac
Max Data Rate	867 Mbps
Operating Frequency	4900-6200 MHz
Ethernet Ports	1 x 10/100/1000 Mbps
Power Method	Passive PoE
MIMO	2x2
Power Supply	Passive PoE
