Mindeo CS2190 - Page 11

2
Note:
1
Test condition: temperature at 27°C, sunny day, and visibility of 5 kilometers. Natural surroundings
significantly affect the communication distance in practice. The distance drops quickly in the rainy,
high-humidity, or heavy haze day; radio interference also shortens the communication distance.
Cradle
Input Voltage
5 ± 0.25 VDC
Current
60 mA (working), 500 mA (charging, maximum)
Cable
Straight 2.0 m (PS/2) / Straight 1.5 m (USB) / Straight 2.0 m (RS-232 )
Dimensions
Length × Width × Depth: 118 mm × 89.5 mm × 74 mm
Weight
140 g
Indicator
LED
Programming Method
Manual (reading special barcode)
Fiermware Upgrade
PC online using Flash Utility software.
Temperature
0° to 50°C (32° to 120°F), operating; -40° to 60°C (-40° to 140°F), storage
Humidity
5% to 95% (non-condensing)
Drop Specifications
Multiple 1.5 m (4.9 ft.) drops to concrete
