Mindeo CS2190 - Specifications Overview; Technical Specifications

1
1 Specifications
1-1 Technical specifications
Handheld unit
Working Range
100 meters
1
(open air)
Radio Link
430.0～431.9 MHz , 433.3～434.7 MHz with adaptive frequency hopping
Weight
207 g
Dimensions
Length × Width × Depth: 90.2 mm × 70 mm × 180 mm
Color
Gray
Indicator
LED, beeper, vibration
Operating Mode
Handheld
Programming Method
Manual (reading special barcode)
Firmware Upgrade
Using Flash Utility software, while a cradle unit is required.
Input Voltage
5 ± 0.25 VDC
Current
4 mA (satndby), 150 mA (working)
Battery
1400 mAh Lithium-ion battery
Charge Time
4 hours
Standby Time
5 days
Operating Time
21 hours (1 scan per 5 second)
Light Source
650 nm visible laser diode
Decoding Rate
200 times per second
Scanning Angle
±60°, ±65°, ±42° (skew, pitch, roll)
Print Contrast
20% minimum reflection difference
Minimum Resolution
3 mil
Decoding Capability
UPC-A, UPC-E, UPC-E1, EAN-13, EAN-8, ISBN (Bookland EAN), ISSN,
Code 39, Code 39 full ASCII, Code 32, Trioptic Code 39, Interleaved 2 of 5,
Industrial 2 of 5, Matrix 2 of 5, Codabar (NW7), Code 128, UCC/EAN 128,
ISBT 128, Code 93, Code 11 (USD-8), MSI/Plessey, UK/Plessey, China Post,
China Finance, GS1 DataBar (formerly RSS) variants
Decoding Depth
3 mil Code 39 (3 chars): 20 - 70 mm
5 mil Code 39 (3 chars): 0 - 120 mm
10 mil Code 39 (3 chars): 0 - 280 mm
13 mil UPC-E (6 chars): 0 - 350 mm
20 mil Code 39 (3 chars): 25 - 480 mm
30 mil Code 39 (2 chars): 15 - 650 mm
Temperature
0° to 50°C (32° to 122°F), operating; -40° to 60°C (-40° to 140°F), storage
Humidity
5% to 95% (non-condensing)
Safety
Laser safety: EN60825-1, Class 1
EMC: EN55022, EN55024
Electrical Safety: EN60950-1
Sealing: IP51
Drop Resistance: Multiple 1.5 m (4.9 ft.) drops to concrete
