Mindray BA-88A Service Manual

5 Service and Maintenance
5-13
2 Locate the position where the peristaltic pump is installed. Pull out the
tubing that goes through the backboard of the analyzer for 40-50mm until
the adapter is exposed. Pinch the two buckles on the left and right side of
the pump shell and detach the pump head carefully.
3 After detaching the pump head, unplug the tubing (yellow) whose adapters
are closer to the pump head.
Unplug the
tubing
(yellow)
whose
adapters
are closer
to the pump
head.
Pinch the
buckles to
detach the
pump head
Pull the
tubing out
slightly
