Mindray BeneHeart D1

E-3
LIMITS
 For CF applied parts: 50 A
 For BF
applied parts: 5000 A
E.6 Patient Auxiliary Current
Patient Auxiliary currents are measured between any selected Applied Part connector and the remaining Applied Part
connector s. All measurements may have a true RMS only response.
The following outlet conditions apply when performing the Patient Auxiliary Current test.
 normal polarity (Normal Condition)
 reverse polarity (Normal Condition)
 normal polarity with open neutral (Single Fault Condition)
 reverse polarity with open neutral (Single Fault Condition)
 normal polarity with open earth (Single Fault Condition)
 reverse polarity with open earth (Single Fault Condition)
LIMITS
For CF
applied parts,
 10A in Normal Condition
 50A in Single Fault Condition
For BF
applied parts,
 100A in Normal Condition
 500A in Single Fault Condition
NOTE
 Make sure the safety analyzer is authorized comply with requirement of IEC61010-1.
 Follow the instructions of the analyzer manufacturer.
