 Touch to place the slice lines vertically, and touch to place the slice lines
horizontally.
 Active slice: the green slice line corresponding plane is the active slice, which is marked
with a green box. The default active slice is the central slice.
 Slice order number: indicating the order of the slices, the order of central slice is ―0‖, the
slices before the central slice are marked with negative integral numbers, and the slices
after the central slice are marked with positive integral numbers.
 Slice position (to the central slice): displayed at the upper left corner of each image,
indicating the position of each image (such as -6mm, -3mm, 3mm, 6mm).
 Coordinate axis: indicated on the A, B, C three reference images, match together with the
central slice line, and will move accordingly with the central slice line.
 Slice shifting
Roll the trackball to shift the crossing point of central axis up/down, left/right, and the slice lines
will shift accordingly with the crossing point.
Rotate the knob under [Range Pos] on the touch screen to fine-tune slice lines horizontally.
 Slice position
Rotate the knob under [Slice position] to move the active slice line (green) either forward or
backward within the range, then the corresponding slice will be highlighted in green.
 Spacing
The value is displayed at the upper right side of the slice, unit: mm. Adjust it through touch
screen selection [Spacing].
 Slices number
Change slices number as necessary using the knob under [Slices Number] on the touch
screen.
 Thickness
Rotate the knob under [Thickness] to adjust the SCV thickness. When the thickness value is
larger than zero, the SCV function is on. (Note: thickness cannot be larger than Spacing.)
Figures below are the effect before and after the SCV function is turned on. You can see the
body structure within the range of the thickness is added to the image after the SCV function is
on.
