5-124 Image Optimization
3. Select the CT/MR volume data disk from the drive drop-list (or portable hard disk, optical disk).
Click [OK].The icon appears after the CT/MR volume data is acquired successfully.
Note:
a) The icon at the right lower corner of the screen shows the progress of the task.
Click the icon to see the progress.
b) The icon appears after all tasks are completed, which implies that the patient data are
loaded to the ultrasound system successfully.
The dialog box does not appear for:
If any file (Ultrasound patient data) is named with ―DC80‖ in the external
storage medium. Please rename the file, and conduct step 2. The dialog
box given above appears then.
If DICOMDIR CT/MR volume data or backup file of the Ultrasound patient
data is in the root directory of USB disk (portable hard disk, optical disk),
the Ultrasound System does not pop up the path. However, CT/MR volume
data or patient data is loaded to iStation data base.
4. Press <Esc> to return to iStation page. Press <F2 iStation> again to enter the iStation page.
You can see the CT/MR volume data which is loaded successfully.
Importing CT/MR Volume Data
Acquire CT/MR volume data to iStation. Then, import the data to Fusion exam with the procedures
below.
1. Press user-defined Fusion key (see also Chapter 12.1.6 Key Configuration) to enter Fusion
Imaging mode. Tap [CT/MR Database]. The page appears as shown below. Select the CT/MR
volume data, and click [OK].
