13-28 Probes and Biopsy
(6) Hold the transducer, and release the pressure position of the needle. Adjust the needle-
type adjusting nut manually (following the direction of the arrow). The needle moves
smoothly at the vertical direction due to its gravity.
NGB-025
(1) Put on the sterile probe sheath.
(2) Open the clamp. Insert the front clamp to the front groove.
(3) Push the needle-guided bracket forward (arrow’s direction) until the locating pole inserting
into the location hole. Turn the lower clamp against the intra-cavity probe. Tighten the nut
to lock the biopsy (arrow’s direction).
NGB-027
(1) Put on the sterile transducer sheath.
Align front clamp with
front groove
Insert the locating pole
into the locating hole
