Mindray DC-80 EXP User Manual

Barcode Reader E-11
1.
Reader holder (cup)
2.
Angle adjustment knob
3.
Height adjustment knob
E.3 Setting in Ultrasound System
Open the Scan Code page via [Setup]  [System]  [Scan Code].
Setting items are described as follows:
Parameter
Description
Bar Code
Reader
Select type: 1D or 2D.
Input Patient
Data mode
Select type: Only Patient ID or Combination Items.
Only Patient ID: Only Patient ID is acquired from barcode reader. If this function is
selected, patient ID can be acquired via barcode reading in Worklist or QR
screen.
Combination Items: patient ID, patient name and other information can be
acquired from barcode. (available only in 2-D barcode reader)
Scan Barcode
Example
When 2-D barcode reader is adopted, you should first scan a sample barcode
here and then set the parts definition for the information.

Mindray DC-80 EXP Specifications

General

Touchscreen	Yes
Transducer Ports	4
Power Supply	100-240V AC, 50/60 Hz
Imaging Modes	Color Doppler, Power Doppler
Operating System	Windows
Storage	1 TB HDD
Connectivity	DICOM, Ethernet, USB
Applications	General Imaging, Cardiology, Vascular, Pediatrics
Weight	85 kg
