5-72 Image Optimization
Other Operation
iLive does not support Inversion mode.
Zoom
Same as those in 3D/4D mode.
Rotation
Roll the trac
kball to view section
al images as n
ecessary; you can
rotate <M>,
<PW>, <Color>
to
perform axial rotation or rotate <4D> knob to adjust the nearest VOI section (cut plane) position.
Comments and Body Marks
Same as those in other modes.
5.10.13 Smart FLC (Smart Follicles Calculation)
Smart FLC result is provided for reference only, not for confirming a diagnosis.
Note: Smart FLC is an optional function, and it is not available in Smart 3D mode.
The probe D7-2E, D8-2E, D6-2NE, DE11-3E and DE10-3E support the Smart FLC function.
5.10.13.1 Basic Procedures
1. Acquire necessary 3D/4D data and freeze.
2. Touch [Smart FLC] tab on the touch screen to enter Smart FLC, and the system is in the ―Edit
ROI‖ status ([Edit ROI] button is highlighted in green);
3. Set the position and size of the ROI box.
4. Touch [Calc] on the touch screen.
5. Auto calculation is finished:
Section image (A, B, C) is enclosed with colored lines and the color corresponds to the
follicle in VR window.
3D image (VR);
Results on the right of the screen are displayed in a table. Includes:
V: volume
d1, d2, d3: diameters of the follicle
MD: mean diameter of the follicle
