P/N: 046-003757-00 Rev A
Quick Reference Guide
14
SCREEN DISPLAY
The DPM 6 and DPM 7 allow the clinician to adjust the main display based on
patient acuity.
To enter the screen selection menu and adjust the main screen’s layout on the
DPM 6 or DPM 7 bedside monitor:
a. Select Screens
(quick key) on main display
Or
a. Select
on main display and Screen Setup menu
b. Select
• Normal Screen: Real time waveforms and numeric parameters on the
main display (Configurable)
• Big Numerics: Up to 4 waveforms and numeric parameters in an
expandable view on the main display
• Minitrends Screen: Split screen with continuously displayed graphic
minitrends on left side besides real time waveforms and numeric
parameters (Configurable) on the main display
• OxyCRG Screen: Split screen with OxyCRG (HR trend, SpO
2
trend, and
RR trend/RR waveform) on the lower portion of the display with real
time waveforms and numeric parameters on the main display
• View Others Screen (optional): Split screen with viewing information
from another bed(s) on the lower portion of the display with real time
waveforms and numeric parameters on the host monitoring device
• ECG 7-Lead Half-Screen (5 lead wire set): 7 Leads of ECG on the upper
portion with real time waveforms and numeric parameters on the
main display
• ECG 7-Lead Full Screen (5 lead wire set): 7 leads of ECG with numeric
parameters on the main display
• PAWP Screen (Optional): Split screen with PAWP measurement
window on the lower portion of the main display with real time
waveforms and numeric parameters on the main display
