Part II General Information

Product Specifications 118

1 Product Specifications

1.1 Product Overview

1.1.1 Intended Use

This product is intended for clinical ultrasound diagnostic examination.

1.1.2 System Appearance

No. Name Description

1 LCD Shows the images and parameters during scanning.

2 Touch screen Serves as a man-machine interface for operations and

control.
