Mindray ME7

Part I Service Scenarios
Update 107
4.3 Upgrading Hardware Functions
4.3.1 Hardware Function List
No. P/N Description Picture Remarks
Installation
Reference
1 115-067777-00 Dual Probe
Extend
Module(FRU)
Installed at
the probe
socket on the
right of the
main unit
2 115-066332-00 ECG
module(AHA/C
E)
USB port See Part I
Service
Scenarios:
1.2.3.2Connecti
ng the ECG
Cable.
115-066503-00 ECG
module(IEC/Ma
de in China)
115-066505-00 ECG
module(AHA\M
ade in China)
3 115-068005-00 Li-ion
battery(FRU)
Only one
battery is
configured
for the main
unit.
See Part II
General
Information:
5.2.2Battery.
4 115-067749-00 Wi-Fi module Used for
wireless
network
connection
See Part II
General
Information:
5.2.3SSD Card.
5 115-067748-00 Kit,4G Module See Part II
General
Information:
5.2.3SSD Card.
6 115-069531-00 4D/TEE/CW
board (FRU)
See Part II
General
Information:
5.2.5Equipment
body.
7 115-067884-00 Probe extend
Module(Pencial
port/For)
Optional for
the trolley
See Part II
General
Information:
5.3.3Extender.
