Part II General Information
Structure
and Assembly
/Disassembly
189
3.
Cab
le betwe
en the contro
l panel and the touch screen
Open the cable cr
imps and take of
f the two cables connecte
d between the control pa
nel and the
touch screen.
4.
Po
wer button
Pull out the p
o
wer keypad
and remove t
he power butto
n cable from
the interface.
FPC flat cable
between
the main boar
d and the
control pa
nel
Cable crimp
Cable
betwee
n the control p
an
el
d the touch
screen
205
