8-10 Field Replaceable Unit

No.

Order Number

Part Name

Qty.

Remark

C14-1/C15-1

024-000693-00

Coupling gel heating cup 12V 12W

C14-2

115-032780-00

Left Gel Warmer Rack Kit

C15-2 115-032781-00 Right Gel Warmer Rack Kit 1

C14-1

C14-2

C15-2

C15-1
