Mindray Nuewa R9 Elite

1-2 Safety precautions
1.2.2 Warning Labels
No.
Warning Labels
Meaning
1.
a. Do not place the device on a sloped surface.
Otherwise the device may slide, resulting in
personal injury or the device malfunction. Two
persons are required to move the device over a
sloped surface.
b. Do not sit on the device.
c. DO NOT push the device. When the casters are
locked.
2.
Mind your hands.
1.2.3 General Symbols
This system uses the symbols listed in the following table, and their meanings are explained as
well.
Symbol Description
Type-BF applied part
Refer to the relevant content in the Operator’s Manual, to avoid safety incidents
AC (Alternating current)
Functional grounding
Equipotentiality
Transducer sockets
Pencil probe port
Network port
USB port
VGA
Used for VGA output.
S-VIDEO
Used for separate video output
AUDIO
Used for stereo audio output.
HDMI
High definition multimedia interface.
Microphone input jack
a
b c
