Structure and Assembly/Disassembly 9-95
2. Unscrew M4 X12(M3*2, M4*2) stainless cross panhead combination screws from the
connecting base to remove the base.
9.3.39.3 Bottom Cover
1. Remove the shield cover from the fixture. Unscrew the M6 X 30 (*4) round inner head screws
(with the pad) with M6 spanner to lift the upper part of the standing pole.
In case of the scratch to the base assembly when removing the standing pole,
check whether the shield cover is lifted completely.
In case of injury to the personnel, hold the standing pole when untightening the
onnecting base assembly
tray
