System Diagnosis and Support 11-9
V008 STB5V
DC box assembly
Source: DC box assembly
Load: PC carrier board assembly, CPU module assembly
V009 AP3V8
DC box assembly
Source: DC box assembly
Load: TR board
V010 AP1V4
DC box assembly
Source: DC box assembly
Load: TR board
V011 AP2V1
DC box assembly
Source: DC box assembly
Load: TR board
V012 DP3V3
DC box assembly
Source: DC box assembly
Load: probe board assembly, engine board, IO assembly
V013 VCC5V
PC carrier board assembly
Source: DC box assembly
Load: PC carrier board assembly
V014 VDD3V3
PC carrier board assembly
Source: DC box assembly
Load: PC carrier board assembly
V015 VDD2V5
PC carrier board assembly
Source: PC carrier board assembly
Load: PC carrier board assembly
V016 VDD1V8
PC carrier board assembly
Source: PC carrier board assembly
Load: PC carrier board assembly
V017 VDD1V5
PC carrier board assembly
Source: PC carrier board assembly
Load: PC carrier board assembly
V018 VDD1V2
PC carrier board assembly
Source: PC carrier board assembly
Load: PC carrier board assembly
V020 VDDN5V7
PC carrier board assembly
Source: DC box assembly
Load: PC carrier board assembly
V019 VBAT
PC carrier board assembly
Source: button battery
Load: CPU module assembly
V021 24V
Lift control panel assembly
Source: AC power supply assembly
Load: electrical lift, electrical lift board
V022 RX1_Vccint
TR board
Source: TR board
Load: TR board
V023 RX1_Vccbram
TR board
Source: TR board
Load: TR board
