TransducerControlsandInspection
14 Operator's Manual
P8-3Ts
1
2
2
3
3
1 Up/DownDeectioncontrolwheel
2 Turnlowerwheelcounterclockwisetomovethetipdown,90
°
minimum
3 Turnlowerwheelclockwisetomovethetipup,120
°
minimum
3.1.3 Brake Operation
The tip deflection brake inspection should be performed on the transducer after taking it out
of the box and prior to each exam.
1. Conrmthebrakeisintheunlockedposition.
2. Deectthetiptotheanteriordirection.
3. Movethebraketothelockedposition.
4. Conrmthatthetipislockedinthedeectedposition.
5. Unlockthebrakeandconrmthetipstraightenseasily.
6. Repeatsteps1-5fortheotherdirections.
P7-3T/P7-3TE
1
2
3
4
1 Left/Rightdeectionlock:white-unlock
2 Left/Rightdeectionlock:red-lock
3 Up/Downdeectionlock:white-unlock
