TransducerControlsandInspection
16 Operator's Manual
3.1.4 Scanplane Rotation Operation
CAUTION
●
Do not use excessive force on the scanplane rotation control wheel at its outer
positions as this may damage the gastroscope mechanism.
●
The transducer scan plane can be rotated from 0° (transversal plane) via 90°
(longitudinal plane) to 180° (transversal plane, left/right inverted). All planes in
between can also be chosen. This makes it possible to scan a conical imaging
volume.
Rotation Control
Figure 3-1 P7-3T/P7-3TE
Figure 3-2 P8-2Ts/P8-2TU
Fororientationpurposes,theusermaychoosetostartscanninginoneofthetransverse
planes,forinstancethestandardmonoplaneindicatedas0°onthesystemmonitor.After
rotatingthescanplane90°,scanningoccursinthelongitudinalplane,sweepingthrough
twooppositequadrantsofthecone.Whenthescanplanerotates90°furtherinthesame
direction,scanningoccursinthemirrorimageofthersttransverseplane.Theonlytwo
planesthatareequivalentarethetwotransverseplanes;onebeingthemirrorimageofthe
other.Asshowningurebelow,a180°rotationofthescanplanellsallfourquadrantsof
theconicimagingvolume.
Thedirectionofthetipoftheendoscopeiseasilysteeredusingthedeflectioncontrol
wheelsonthehandleoftheinstrumenttoallowexactpositioningofthetransducerinthe
esophagus.
