Mindray PM-60 Service Manual

3-4
3.4 Performance Tests
3.4.1 SpO
2
Test
Required tool: SpO
2
simulator
1. Connect the pulse oximeter with the SpO
2
sensor.
2. Connect the SpO
2
sensor with the SpO
2
simulator.
3. Select the model and manufacturer of the SpO
2
module under test; set SpO
2
to 96% and
PR to 80 bmp.
4. The SpO
2
and PR readings should be within the ranges listed below.
SpO2 (%) PR (bmp)
96%±2% 80±3
3.4.2 SpO
2
Test in Motion Mode
Required tool: SpO
2
simulator.
1. Connect the pulse oximeter with the SpO
2
sensor.
2. Connect the SpO
2
sensor with the SpO
2
simulator.
3. Select the model and manufacturer of the SpO
2
module under test; take measurement in
the motion mode preset by the SpO
2
simulator.
4. The SpO
2
and PR readings should be within the ranges listed below.
SpO2 (%) PR (bmp)
±3% ±5
NOTE
z The SpO
2
simulator can only be used to verify that the pulse oximeter operates
properly. It cannot be used to verify the accuracy of the pulse oximeter or the SpO
2
sensor. To verify the accuracy, clinical tests are required.

Mindray PM-60 Specifications

General

Data Storage	Up to 72 hours of trend data
Device Type	Handheld Pulse Oximeter
Display	TFT LCD
Measurement Range	SpO2: 0-100%
Power Supply	AC Adapter
