Mindray PM-60 Service Manual

5-6
CAUTION
z Do not touch the LCD screen.
z Disassemble the LCD screen in an environment as dust-free as possible.
5.3.5 Remove the Screen Mount
Use sharp-nose pliers to straighten the three clips that secure the screen mount to the main
board. Remove the screen mount.

Mindray PM-60 Specifications

General

Data Storage	Up to 72 hours of trend data
Device Type	Handheld Pulse Oximeter
Display	TFT LCD
Measurement Range	SpO2: 0-100%
Power Supply	AC Adapter
