Mindray PM-60 Service Manual

5-3
2. Remove the adjusting bracket.
3. Unscrew 2 M2X6 crosshead screws and 3 PT2X8 tapping screws. Separate the front
panel from the rear cover with your hands.
NOTE
z Carefully separate the covers to avoid damage the wires and connectors.

Mindray PM-60 Specifications

General

Data Storage	Up to 72 hours of trend data
Device Type	Handheld Pulse Oximeter
Display	TFT LCD
Measurement Range	SpO2: 0-100%
Power Supply	AC Adapter
