3-16 System Preparation
NO. Item Description
8.
Patient Information
Area
Displays the hospital name, patient name, exam mode,
probe model, exam time, date, operator, patient ID, DOB,
3.7.2 Basic Operations of Dialogue Box
A dialogue box screen consists of title, page tabs, contents and buttons, as shown in the following
figure:
Component Description
Title Bar The title bar is used to give a description for the content and function of the screen.
Page Tab
For some screens, contents are distributed into several pages. Use <Set> to open/close
the available pages.
Content
Radio box: click to select the item.
Check box: click to check or uncheck the item.
Entry box: enter characters manually via the keyboard.
Drop-down list: click to show the list and select an item.
[OK] and
[Cancel]
When the operation of a screen is completed, click the [OK] or [Cancel] button to save
or cancel the operation, and close the screen.
To reposition a dialogue box:
1. Roll the trackball to move the cursor onto the title bar of the dialogue box. At this time the cursor
becomes a
; press <Set> key.
2. Roll the trackball and posit the rectangular graphic to the new desired location.
3. Release <Set> key, and the dialogue box is moved to the desired position.
