Machine Disassembly/Assembly and Troubleshooting
4-2
4.1.2 Master bracket (lead-acid battery) assembly
Figure 2 Master bracket (lead-acid battery) assembly
No. Std. Code Name & Spec. Qty.
1 6006-20-39367 Main bracket (lead-acid battery) 1
2 6006-30-39448 Lead-acid battery assembly 1
3 M04-004015--- Gasketed cross-head screw M3*8 4
4 6006-20-39385 Speaker & connection cables 1
5 6006-20-39379 Washer of speaker 1
6 6006-20-39464 Insulating plate of power board 1
