Machine Disassembly/Assembly and Troubleshooting
4-12
4.2 Inter-board Connections
4.2.1 List of Connection Cables
4.2.1.1 Signal lines
Name Material number Graphic connection relations
MINDRAY 9006 SPO2 signal line 6006-21-39390 See the figure below.
NELLCORE SPO2 signal line 6006-21-39392 See the figure below.
MASIMO SPO2 signal line 6006-21-39391 See the figure below.
4.2.1.2 Internal Connection Cables
Name Material number Graphic connection relations
Main board power cord
6006-20-39380
See the figure below.
Recorder signal line
6006-20-39381
See the figure below.
SpO2 module connection cables
6006-20-39382
See the figure below.
Keypad signal line
6006-20-39383
See the figure below.
LCD signal line
6006-20-39384
See the figure below.
Speaker and connection cables
6006-21-39385
See the figure below.
Power board AC input cables
6006-21-39386
See the figure below.
Fan and connection cables 6006-21-39387
See the figure
below.
Power board-to-battery backplate
connection cables (lithium)
6006-20-39388
See the figure below.
Power board-to-battery backplate
connection cables (lead-acid)
6006-20-39389
See the figure below.
Recorder power cord 6006-20-39492
See the figure below.
Keypad power connection cables 6006-20-39493
See the figure below.
NIBP module connection cables 6006-20-39494
See the figure below.
TEMP module connection cables
M09A-20-62082
See the figure below.
