Minebea CSA-562B - General; 1−1. Features; Name and Function of each Point; 2−1. Front Panel

1
1. General
1−1. Features
1
Specialized transmitter
Specialized transmitter for exclusive use of optical transformer method torque transducer.
2
Digital display monitor
4 1/2 digit of digital display is adopted for voltage output monitor, and 1 mV monitoring is
available.
2. Name and function of each point
2−1. Front panel
1
2
3
4
6
7
8
9
10
5
1
Monitor
Displays the output voltage digitally. (Minimum digit is 1 mV.)
2
ZERO trimmer
For initial balance adjustment.
3
SPAN trimmer
For sensitivity adjustment.
