20
Occupies 1 station
Device NO.
Buffer address Contents Classification
RX0000
00E0
⑦S0
Control output
RX0001
00E0
⑦S1
Control
output
RX0002
⑦S2
RX0003
RX0004
RX0005
RX0006
RX0007
RX0008
⑧In the holding
RX0009
RX000A
RX000B
RX000C
RX000D
RX000E
RX000F
⑨Abnormal load value
RX0010
00E1
RX0011
00E1
RX0012
RX0013
RX0014
RX0015
RX0016
RX0017
RX0018
RX0019
⑩Initial data setting request flag
RX001A
⑪Error reset request flag
RX001B
⑫Remote ready
RX001C
RX001D
RX001E
RX001F
1
Setting value writing response (Response 1)
The end of writing by the set value writing request (request 1) is notified.
ON ：In completion of writing
OFF ：After confirming OFF of “Setting value writing request(Request 1)”
2
General command response (Response 2)
The end of the command instruction by the general command request (request 2) is notified.
ON ：In the completion of command instruction
OFF ：After confirming OFF of the general command request (Request 2)
3
Writing/R eading out selecting response (R/W response)
Notify the status of write/reading out by the command instruction when notifying by the
general command response (response 2).
4
Operating mode changeover response(Response 3)
Notify that the end of the operation mode changeover by the operation mode changeover
request (request 3(RY0004)).
ON ：In the completion of the changeover
OFF ：After confirming the OFF of the operation mode changeover request(Request 3)
