Minelab SDC 2300 User Manual

15
Detector Technical Specifications
Coil
8" round monoloop
Audio output
Built-in speaker
Headphones (standard accessory, supplied)
Waterproof headphones (optional accessory, not supplied)
Display
9 LEDs indicate detection, battery status and threshold level
1 low battery warning LED
Length
Extended: 1500 mm (59.1")
Collapsed: 400 mm (15.7")
Weight
2.3 kg (5.1 lbs) (excluding batteries and headphones)
Operating
temperature range
0°C to 50°C (32°F to 122°F)
Storage
temperature range
–33°C to 70°C (–27°F to 158°F)
Batteries
Lithium-Ion 7.4 V 32 Wh (8-hour battery life, battery and
charger included)
C cell 4 × 1.2 V NiMH, 1.5 V Alkaline, 1.2 V Ni-Cad (optional)
Lithium-Ion charger
Output voltage: 10 V to 15 V
Output current: 1 A
Detecting mode
Normal mode (1–5 sensitivity)
Salt mode (1–3 sensitivity)
Noise cancel
Automatic scanning
Ground balance
Automatic Ground Tracking (AGT)
Fast ground balance
Threshold
9 audio levels
Audio pitch (tone)
Low | High
Transmission
Pulse Induction (PI)
Technology
Multi Period Fast (MPF)
Optional accessories
Waterproof headphones, carry bag
Technical Specifications

Minelab SDC 2300 Specifications

General

Type	Gold Detector
Collapsible	Yes
Target ID	No
Ground Balance	Automatic
Technology	Pulse Induction
Waterproof	Yes, up to 3 meters
Coil Size	8-inch round
Audio Output	Internal speaker or headphones
Length Extended	1500 mm
Display	No
Battery Life	Up to 8 hours
Coil Type	Monoloop
